Aiko 645W Bifacial Solar Panel

Description

The Aiko 645W Bifacial Solar Panel integrates advanced N-type ABC (All Back Contact) cell technology with a bifacial, dual-glass design to maximize energy harvest from both front and rear surfaces. With high module efficiency (\~23.9%), robust engineering for extreme environments, and long-term reliability, it’s ideal for large-scale commercial, utility, and solar farm projects in Pakistan.

Specifications

• Brand: Aiko Solar
• Model: AIKO-G645-MCH72Dw (Stellar 1N+)
• Panel Type: Bifacial (Glass–Glass dual tempered glass, 2.0 mm + 2.0 mm)
• Power Output: 645 Watts (STC)
• Module Efficiency: \~23.9%
• Cell Technology: N-Type ABC (All Back Contact)
• Cell Size & Count: 182 mm, 144 half-cut cells (6 × 24)
• Front/Back Glass: Dual-Glass, 2.0 mm tempered (front and back)
• Backsheet / Frame: Silver anodized aluminum alloy frame; glass–glass eliminates traditional backsheet
• Dimensions: approx. 2382 × 1134 × 30 mm
• Weight: 32.3kg±3%
• Connector Type: MC4-EVO2; Cable length \~1400 mm with 4 mm² cross-section
• Maximum System Voltage: 1500 V DC
• Operating Temperature: -40 °C to +85 °C
• Mechanical Load: 5400 Pa / 2400 Pa
• Temperature Coefficient (Pmax): -0.26% / °C
• Warranty: 15 Years Product Warranty; 30 Years Linear Performance Warranty
